Reduce friction and minimize wear
Cooling, prevent bearing overheating
Clean the system and prevent contaminants from entering
Corrosion protection, extend the lifespan of components
Bearings are the core wear-prone components of crushers
Poor lubrication is the main cause of high failure rates in jaw crushers, cone crushers, and impact crushers
Proper lubrication can extend equipment lifespan by more than 30%
Type
Features
Applicable Equipment
Grease lubrication
Simple and easy to operate, but requires regular replacement
Small jaw crushers, impact crushers
Oil circulation lubrication
Constant oil temperature, automatic circulation, good heat dissipation
Medium and large jaw crushers, cone crushers, multi-cylinder hydraulic cone crushers
Oil-water mixed cooling
Used in high-temperature environments, reduces bearing temperature
High-capacity crushers, continuous operation equipment
Truth:
Many manufacturers recommend “multi-purpose lubricating oil,” but not replacing the filter = equivalent to wasting the oil
Grease lubrication is suitable for small equipment, but high output and high-hardness materials must use an oil circulation system
Small crushers → 40#–50# lithium-based grease
Medium and large crushers → mineral oil or synthetic oil (ISO VG32–46)
High-temperature environment → high-temperature-resistant lubricating oil
Dusty environment → high-viscosity oil to reduce wear
Grease: replace once every 500–1000 hours
Oil circulation system: replace every 3000 hours or according to oil quality testing
Observe oil temperature, oil level, and whether pipelines are leaking
Check bearing vibration and noise
Replace lubricating oil/grease
Clean oil tank and filter
Check oil pump, pipelines, and joints
Abnormal bearing temperature → insufficient oil quantity or degraded oil quality
Increased noise → insufficient lubrication or contaminant intrusion
Leakage → aging pipelines or loose joints
Misconception 1: The more oil added, the better
Actual: Excess will cause heating and contaminate bearings
Misconception 2: Only change oil without cleaning the filter
Filter blockage = poor oil circulation → high failure rate
Misconception 3: No cooling under high temperature
Lubricating oil temperature too high → viscosity decreases, protection fails
1️⃣ Select lubrication method and oil type according to the equipment manual
2️⃣ Establish a lubrication record sheet and operate according to shifts/cycles
3️⃣ Regularly test oil quality and bearing condition
4️⃣ Large production lines adopt automatic lubrication + oil temperature monitoring
If you want to reduce crusher failure rate and extend lifespan, please provide:
Crusher model
Production capacity and raw material type
Current lubrication method
We can provide:
✅ Professional lubrication solutions
✅ Customized maintenance plans
✅ Equipment maintenance training
