Product Introduction

The mill has many features as following: unique structure, innovative design, excellence performance, reliable running, energy-efficience. It can used for construction, metallurgy, mining, electricity, chemicals etc, for grinding (or super-crushing) of cement, cement raw materials, iron ore, slag, limestone, dolomite, feldspar, quartz, serpentine, barite, fluorite, shale, coal gangue, coal, lime, gypsum, calcium carbide and so on. From the investment, power consumption, wearing parts wear, the adaptability of material moisture, are the level of technology and processs conditions ideal for pre-ground equipment. The system provides energy saving production, reduce production costs and improve the quality of concentrate greater profit margins, and overall improve the development and utilization of mineral resources.

Photos

Advantages

1. While grinds 1.5mm limestone, the roller wheel and liner wear less than 5g/t, can be used continuously for 1-2 years.

2. The machine operates with low noise. There is no blower in conical mill, in this case there is nearly no dust pollution. It has a proper ventilation in the bottom of the machine, the result will be better.

3. During maintenance, you just need to do lubrication on time. There is less breakdown, high running rate. Longer working life for wearable parts. Easy to change wearable part. Roller can be repaired by surfacing.

4. Lower power consumption. During grinding 1.5mm limestone coarse powder, the unit power consumption is 6-10kWh/t.

Working Principle

The structure is reasonable,transmit from the upper part of the machine, main mill driven by the reducer, there are three to four roller installed in the main shaft turn around on the ring. The material is feed from top, deposit into the space between roller and annular conical liner. After the roller grinding again and again, it becomes into powder, discharge from bottom, transfer through bucket elevator, then goes into powder separator. The fine powder is production. Coarse powder is returned back to re-grind again. The roller and grinding ring gap, main shaft speed, the spring pressure and material thickness, can be adjusted according to the fineness of the finished product.

Technology Parameters
